CAST IRON CLAMPS | Force Tooling
FX Xtreme Clamps – from 200-1400mm Long – from 95-140mm Throat
This XTREMEly heavy duty clamp is a tool your Grandchildren will inherit.
The unique design gives you over 70% more clamping force than heavy duty conventional F-clamps.
- The Unique internal ball bearing removes friction allowing greater precision and more clamping force
- Completely sealed thread means no welding slag damage
- Totally sealed means permanently lubricated
- Dependable braking system (hardened steel) for total confidence
- Trapezoidal thread means more force for clamping and more ease for release
- Suited to all environments and applications including welding, working with fluids, humid or salty atmosphere
- Patented
- Lifetime Guarantee
- Made in Spain
Accessories;
Magnetic jaws for non-parallel clamping applications such as tube or pipe
Aluminium easy grip handle allows you to tighten quicker
-
- Swivel for difficult applications and angles
- For use with FX Extreme Clamps
| Clamping Force | Solid Bar (a) | Bar Opening (b) | Jaw Depth (c) |
|---|---|---|---|
| 800kg | 30 x 8mm | 200mm | 95mm |
| 1200kg | 35 x 8mm | 200mm | 120mm |
| 800kg | 30 x 8mm | 300mm | 95mm |
| 1200kg | 35 x 8mm | 300mm | 120mm |
| 1200kg | 35 x 8mm | 400mm | 120mm |
| 1800kg | 40 x 10mm | 400mm | 140mm |
| 1200kg | 35 x 8mm | 600mm | 120mm |
| 1800kg | 40 x 10mm | 600mm | 140mm |
| 1200kg | 35 x 8mm | 800mm | 120mm |
| 1200kg | 35 x 8mm | 1000mm | 120mm |
| 1200kg | 35 x 8mm | 1200mm | 120mm |
| 1200kg | 35 x 8mm | 1400mm | 120mm |
